Wheelbuilding | Alloy Rim Weights

Posted by Elite Custom on

To help pick out the appropriate set of rims for your custom wheel build, we've broken them into two main groups: Standard Rims & Disc Rims.

To make things easier, we've further broken these groups into Categories, based on their dimensions. (ie Width and Depth) and sorted them according to their Weight. These 3 specifications are the main attributes to consider to optimise your ride performance and overall experience.

Here are some bullet points to help you along:

  • style of riding (ie, criterium, century, touring)
  • terrain (ie, tarmac, gravel, cobbles)
  • distance
  • gradient
  • wind conditions
  • optimal tyre size
  • frame / brake clearance

--------------------------

Need assistance? Email: info@elitecustom.sg

--------------------------

Standard Rims - CAT A - Narrow / Shallow

Width: 19-23 | Depth: 14-29

Brand Model Weight Depth Width Tubeless
E.22 X2 (Gen2) 375 22 20 No
Stans NoTubes Alpha 340 385 22.6 20 Yes
American Classic RD2218 395 18 22.3 Yes
Stans NoTubes Alpha 400 425 22.6 20 Yes
DT Swiss RR 411 435 21 22 Yes
DT Swiss RR 411 Asymmetric 435 21 22 Yes
Mavic Open Pro 435 18.4 19.6 No
Kinlin XR270 440 27 19.4 No
Velocity A23 Off Center 444 19.5 23 Yes
DT Swiss RR 440 450 21 21 Yes
DT Swiss RR 440 Asymmetric 450 21.7 21 Yes
Velocity A23 451 19.5 23 Yes
DT Swiss R 460 460 23 23 Yes
HED Belgium C2 462 24 23 No
H Plus Son Archetype 470 25 23 No
Mavic CXP Pro 470 23.6 19.4 No
H Plus Son TB14 490 14 23 No
Ambrosio RV26 495 26 22 Yes



Standard Rims - CAT B - Narrow / Deep

Width: 19-23 | Depth: 30-42

Brand Model Weight Depth Width Tubeless
E.22 X3 (Gen2) 445 31 20 No
E.22 X4 530 38 20 No
DT Swiss RR 511 530 32 22 Yes
Velocity Deep V 530 30 19 No
Ambrosio RV30 550 30 22 Yes
Ambrosio FCS30 580 30 20 No
DT Swiss RR 585 585 30.3 19.5 No
H Plus Son SL42 615 42 20 No



Standard Rims - CAT C - Wide / Shallow

Width: 23-25 | Depth: 19-29

Brand Model Weight Depth Width Tubeless
E.22 AGN - T2 440 22 24.5 Yes
Easton R90 SL 455 27 24 Yes
Pacenti SL23 465 26 24.5 Yes
Pacenti Forza 465 25 24 Yes
Pacenti Forza Asymmetrical 465 25 24 Yes
HED Belgium + 469 24 25 Yes
Velocity Fusion 475 25 25 No
Zipp 30 Course 518 26 25 Yes
DT Swiss TK 540 545 20.2 23.6 No
Mavic A-719 565 19.8 24.5 No
Mavic A-319 595 19.8 24.5 No
Velocity Atlas 620 18 25.4 No



Standard Rims - CAT D - Wide / Deep

Width: 23-25 | Depth: 30-42

Brand Model Weight Depth Width Tubeless
E.22 AGN - T3 470 31 24.5 Yes



--------------------------

Disc Rims - CAT A - Shallow

Width: 20-25 | Depth: 20-29

Brand Model Weight Depth Width Tubeless
E.22 AGN - T2 Disc 410 22 24.5 Yes
DT Swiss RR 411 DB Asymmetric 410 21 22 Yes
Easton R90 SL Disc 445 27 24 Yes
DT Swiss R 460 DB 450 23 23 Yes
H Plus Son The Hydra 455 23 25 Yes
Stans NoTubes ZTR Grail Disc 460 24.5 24.1 Yes
HED Belgium C2 Disc 462 24 23 No
Velocity Aileron 465 28 25 Yes
Pacenti Forza Asymmetrical Disc 465 25 24 Yes
HED Belgium + 468 24 25 Yes
Zipp 30 Course 489 26 25 Yes



Disc Rims - CAT B - Deep

Width: 20-25 | Depth: 30-43

Brand Model Weight Depth Width Tubeless
E.22 AGN - T3 Disc 485 31 24.5 Yes
DT Swiss RR 511 DB 490 32 22 Yes
Ambrosio RD30 525 30 22 Yes
H Plus Son F30 540 30 20 No
E.22 X4 Disc 550 38 20 No
H Plus Son Formation Face 615 42 20 No
H Plus Son EERO 790 43 22 No
