E.22 by Elite Wheelworks | AGN - T2 - Rim Only

E.22 by Elite Wheelworks | AGN - T2 - Rim Only

AGN_T2_20H
SGD 150.00 SGD 160.50 Save SGD 10.50

Taking a modern approach, all Avant-Garde Nuance (AGN) rims feature lightweight, wide sections that are optimised for 25-28mm tires. It threads closely to the upper limit for most road frames, but maximises the tangible benefits of high volume, fast rolling tyres, resulting in more speed, comfort and traction on all road surfaces. The AGN also feature a completely new rim bed design for tubeless compatibility across all models, along with hooks that mate perfectly to form flawless seals. With a wider cross section, we've managed to create a rim with increased lateral stiffness

In terms of finished aesthetics, our uniquely blasted, hard anodised-finish sees a degree of improvement over the X-Series, in view that many would consider the AGN as a lightweight pair of wheels for Gravel, CX or Touring with just a mere swap of tires. It is topped off with our logo, laser-etched on.

---------------------------

Our E.22 wheelsets are offered in an array of premium hubs to fulfil the needs and preference of the rider.

Each E.22 wheelset is handbuilt by one of our in-house wheelbuilders. Upon purchase, our wheelbuilders will get in touch with you, to confirm the colours of your components.

---------------------------

There are several factors that attribute to the strength, weight and durability of our rims.

If you refer the cross sections above, there are two things you would notice about the competitor's rim.

The first is, there are voids that surround the cross section, and this runs throughout the entire joint section of the rim.

Second, the competitor's rim has walls that are thicker than the E.22. We were able to achieve unparalleled strength and weight qualities in our rims because of a unique alloy that was used in its creation. Nothing is spared, starting with the base material which is largely, high quality aluminium from Australia and proprietary processes after extrusion. The result was a material with twice the tensile strength of conventional alloys.

---------------------------

Notes
- Fits 23-28mm tyres. (Optimized for 25-28mm)
- Fits both Clincher and Tubeless Clincher tyres
- For best performance tubeless clincher - use Enve SES Road Tire
- Available as Standard Road, or Dedicated Disc variant.

---------------------------

Summary
Material: Our rims are created from a unique alloy, with high quality aluminium originating from Australia as the base material.
Manufacture: A proprietary cold working process is applied to improve strength.
Finishing: Sandblasted - Hard Anodised Black
Brake Wall: CNC - Hard Anodised, Black
Logo: Laser Etched





Q: What is the Black brake track for?

A: Purely Aesthetic, but 100% functional. It was initially designed for track and fixed gear riders with little or no intention of utilizing the brake track. It would also appeal to those who might want a pair of road-disc or cross-disc clinchers. That said, they seem to be gaining popularity with the roadies, as the market trends towards alloy rims that are black and stealthy.

Q: Is the Black brake track ceramic?

A: No, we've worked on and tested a number of ceramic brake tracks, but they always chipped and they ultimately resulted in unwanted pulsation and rough braking. Instead, the surface of our brake track is hard anodised.

Q: Will braking remove the Black brake track?

A: Friction from braking removes material from the surface, even on the CNC-ed Silver variant. However, since only the surface is Black , the wear-and-tear is more noticeable as it turns to silver.

Q: Do I need to use special brake pads?

A: It is not absolutely necessary, but softer pads would preserve the Black coating for a slightly longer period. Pads from Swiss-Stop and Kool Stop work best in this application, whilst Shimano pads wear the brake track much quicker.

Users are also advised to use new brake pads as old brake pads would contain shards of metal that would accelerate wear-and-tear on the brake tracks. Hard braking in wet weather would also attribute to additional friction and premature wear-and-tear.

Check out the Warranty and FAQ page before purchasing.

Read more about: Avant-Garde Nuance (AGN)

For an easy comparison, read: Alloy Rim Weight / Dimension Comparison Chart
